SA-320CR High-Speed Door
SA-320CR High-Speed Door
| Application Scenario | Clean Room, Indoor Passage |
| Features | Rapid switching, high sealing performance, self-repairing system |
| Maximum Dimensions | 4000 × 4000 |
| Maximum Speed | 1.5 m/s |
| Door Structure | Stainless steel |
| Curtain Thickness | 0.8 mm |
| Track | Stainless steel |
| Housing | Stainless steel |
| Viewing Window | Optional |
| Control System | SCILEAD-3 |
| Motor | SCILEAD-320CR |
| Power Supply | 220V |
| Sensor Protection | Infrared photoelectric protection |
| Safety Edge | Wireless safety edge |
| Curtain Colors | Blue RAL5002, Yellow RAL1003, Gray RAL7035, Red RAL2004 |
